Features

• Ultra-fast Maximum Power Point Tracking (MPPT).
• Advanced Maximum Power Point Detection in case of partial shading conditions.
• Outstanding conversion efficiency.
• Flexible charge algorithm.
• Extensive electronic protection.
• Internal temperature sensor.
• Real-time data display options.

Technical Specifications

• Battery voltage: 12/24V Auto Select.
• Rated charge current: 50A.
• Maximum PV power, 12V (1a, b): 700W.
• Maximum PV power, 24V (1a, b): 1400W.
• Maximum PV open circuit voltage: 100V.
• Maximum PV short circuit current 2): 50A.
• Maximum efficiency: 98%.
• Self-consumption: 10 mA.
• Charge voltage 'absorption': Default setting: 14,4V / 28,8V (adjustable).
• Charge voltage 'float': Default setting: 13,8V / 27,6V (adjustable).
• Charge algorithm: multi-stage adaptive.
• Temperature compensation: -16 mV / °C resp. -32 mV / °C.
• Protection: Battery reverse polarity (fuse, not user accessible); PV reverse polarity; Output short circuit; Over temperature.
• Operating temperature: -30 to 60°C (full rated output up to 40°C).
• Humidity: 95%, non-condensing.
• Data communication port: VE.Direct.
