KEY FEATURES
- Brand-new battle-style layout
- Bigger jog wheels
- Lever FX
- Tracking Scratch: Get a helping hand with scratching
- Mixed microphone audio: Easily add your voice while you’re streaming
- Deck 3/4 control
- Class compliant
DESCRIPTION
The DDJ-REV1 matches perfectly with the free Serato DJ Lite software, boasting a brand-new battle-style layout that’s easy to use and perfect for playing like a pro. The design of this 2-channel DJ controller emulates a professional DJM-S mixer PLX turntable setup, including specialized features for open-format and scratch DJs.
Get hands-on with an interface designed to emulate 2 x PLX turntables and a DJM-S series mixer – the kind of setup used by pro battle DJs. There’s plenty of space to perform mixing and scratching techniques thanks to the new arrangement of the controls on the DDJ-REV1. The tempo sliders are 60mm – longer than those on the DDJ-SB3 to give you finer control – and they run horizontally above the decks while the Performance Pads have been moved into the mixer section so you can intuitively combine effects, trigger samples, and scratch your tracks.
SPECIFICATIONS
Width | 20.71 in |
Height | 2.33 in |
Depth | 10.06 in |
Weight |
4.63 lb |
Soundcard | 24 bit/48 kHz |
Frequency Range | 20 - 20000 Hz |
Signal-to-Noise Ratio | 103 dB |
Distortion | < 0.005 % |
Power Supply | USB Type-B bus powered |
Power Consumption | 5V 500mA |
Inputs |
1 MIC (1/4 inch TS Jack) |
Outputs | 1 MASTER (RCA) 1 PHONES (3.5-mm stereo mini jack) |
USB | 1 USB B port |
