Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Capacitance | 4700 uF |
| Capacitance Range | 1000 to 9999 uF |
| Case Size | 3.031 In. Dia. x 4.528 In. L (77 mm Dia. x 115 mm L) |
| Configuration | Radial, Can |
| Element Material | Aluminum Electrolytic |
| ESR | 30 mOhms |
| Lead Spacing | 1.252 In. (31.80 mm) |
| Maximum Operating Temperature | 85 C |
| Minimum Operating Temperature | -40 C |
| Series | |
| Termination | Screw Terminal |
| Tolerance | 20 % |
| Voltage Rating | 450 VDC |
Overview
KEMET's ALS30/31 Series of screw terminal capacitors covers a wide range of case sizes and voltage ratings featuring high ripple currents and long-life performance. They are ideally suited for industrial and commercial applications demanding high reliability and long-life expectancy such as frequency converters, uninterruptible power supply (UPS) systems and switch mode power supplies (SMPS).
Typical applications for KEMET's ALS30/31 Series of capacitors include smoothing, energy storage or pulse operation in telecommunication demanding power supplies, process control, AC motor control, traction, welding, and measuring.
Benefits:
