Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Capacitance | 3300 uF |
| Capacitance Range | 1000 to 9999 uF |
| Case Size | 2.5 In. Dia. x 4.134 In. L (63.5 mm Dia. x 105 mm L) |
| Configuration | Radial, Can |
| Element Material | Aluminum Electrolytic |
| ESR | 54 mOhms |
| Lead Spacing | 1.122 In. (28.50 mm) |
| Maximum Operating Temperature | 85 C |
| Minimum Operating Temperature | -40 C |
| Series | |
| Termination | Screw Terminal |
| Tolerance | 20 % |
| Voltage Rating | 400 VDC |
Overview
KEMET's ALS30/31 Series of screw terminal capacitors covers a wide range of case sizes and voltage ratings featuring high ripple currents and long-life performance. They are ideally suited for industrial and commercial applications demanding high reliability and long-life expectancy such as frequency converters, uninterruptible power supply (UPS) systems and switch mode power supplies (SMPS).
Typical applications for KEMET's ALS30/31 Series of capacitors include smoothing, energy storage or pulse operation in telecommunication demanding power supplies, process control, AC motor control, traction, welding, and measuring.
Benefits:
